Name

Date

Unit

Number of connection points

2

Number of potentials

1

Color

gray

Length

30.5

mm

Width

5

mm

With U-rail height

42.5

mm

Pollution degree

3

Insulation material group

Ⅰ

Rated surge voltage

8

KV

Meet standard①

IEC60947-7-1

Rated voltage ①

800

V

Nominal current①

24

A

Meet standard②

UL1059

Rated voltage②

600

V

Nominal current②

20

A

Min.connection capacity for solid wire

0.08/28

mm²/AWG

Max.connection capacity for solid wire

2.5/14

mm²/AWG

Min.connection capacity for strand wire

0.08/28

mm²/AWG

Max.connection capacity for strand wire

2.5/14

mm²/AWG

Line direciton

side inlet

Strip length

9

mm

Insulation material

PA66

Flame-retarded Rating

UL94 V-0
